Cartridge Filtration

Precision titanium stick filter

Precision titanium stick filter

Model: JTGTB

Brand: JHENTEN

Metal powder backwash filter

Detail Description

JTGTB Precision titanium stick filter suitable for filtering the high temperature ,high pressure and high solid content of the material .Filter adopts back washing method, can be continuous and automatic operation, avoid frequent manual cleaning and unnecessary stops; and maximize reduce pollution tothe environment caused by filter and residue.

Precision titanium stick filtercan remove heterochromia,odor and mercury, lead, cadmium, zinc, iron, manganese,and chromium etc heavy metal material in water, also can remove the arsenic , hydride , sulphide, residual chlorine etc high molecular compound and strontium, radium etc radioactive substances in water, kill and remove the bacteria and e.coli and other carcinogens in the water; Widely used for solid-liquid separation of food,beverage ,pharmaceutical,chemical etc industry.especially in the pharmaceutical industry is suitable for the decarburization filtration of transfusion injection production line


Feature

? TPF-A with performance of resistance to high temperature, high pressure ,strong acid, strong alkali, corrosion resistant. through acid and alkali washing ,soaking can be repeated use.


Application

? Electronics industry: electronic, microelectronics, semiconductor industry water etc filtration.
? Pharmaceutical industry: pharmaceutical raw materials,Solvent liquid, decarburization filtration of material etc filtration.
? Chemical industry: organic solvent, chemical reagents, liquid materials, catalyst etc filtration.
? Food industry: beer, beverage, mineral water, vegetable oil, soy sauce, vinegar etc filtration.
?Oil refining industry: oilfield reflux water filtration, reverse osmosis desalination field filtration.


Surface

Finish

TreatmentType

mechanical polishing

Polishingprecision

Innerwall  0.4μm,outerwall  0.6μm


Material

Filtershell

304、316L

Ventvalve , drain valve

304、316L

Eyebolt

304

Feet

304

O-ring

EPDM ,PTFE , Viton , Silicone


Operating

Conditions

Maxoperating pressure

0.6MPa

Maxoperating Temp.

200℃


Connection

Shellconnection

Flange(eyebolt)

In-outlet

Quick-open, flange, thread

Blowoffvalve

Quick-open

Pressure  gauge (optional)

Thread,quick-open

Ventvalve

Thread

Sediment

Pneumaticcontrol self-locking type discharge door , quick-open


Structure



Selection


[Shelldiameter]

[Shellmaterial]

[In-outletConnection]

[O-ring]

JTGTB

1000T

4

K

S


1000T=diameter Φ1000Titanium rod filtration
(thesame as below)

4= 304

F=flange

E=EPDM


1300T

6= 316L

K=quick-open

P=PTFE


1800T


L=thread

V=Viton


2500T



S=Silicone
